TSW040
Overview
The TSW040 is an unmanaged 8-port PoE+ switch by Teltonika, featuring eight RJ45 ports with a total power budget of 240 W, or up to 30 W per port. This compact and rugged 8-port switch also features a 2-pin power input and an integrated DIN rail for easy mounting, making it ideal for industrial applications. The TSW040 has a wide voltage range of 7-57 VDC and a PoE-out voltage range of 44-57 VDC.
8 X PoE-out RJ45
Eight PoE-out Ethernet ports with a total power budget of 240 W.
2-pin Power Input
Simple and suitable for industrial applications.
Integrated DIN Rail
Easy mounting for plug-and-play deployment.
Wide Voltage Range
7-57 VDC, or 44-57 VDC for PoE-out.
| Industrial switch | |
|---|---|
| Profinet | Profinet Class A conformance (available with optional order code) |
| ETH | 8 x ETH ports, 10/100 Mbps, supports auto MDI/MDIX crossover |
| IEEE 802.3 series standards | 802.3i, 802.3u, 802.3ab, 802.3x, 802.3az |
| PoE+ ports | Port 1 - 8 |
| PoE standards | IEEE 802.3af (PoE, Type 1) and IEEE 802.3at (PoE+, Type 2) compliant PSE ports, over spare pairs (Mode B) |
| PoE Max Power per Port (at PSE) | 30 W |
| Total PoE Power Budget (at PSE) | 240 W |
| Operating temperature | -40 °C to 75 °C |
| Operating humidity | 5% to 95% non-condensing |
| Ingress Protection Rating | IP30 |
| Bandwidth (Non-blocking) | 20 Gbps |
| Jumbo frame support | 9216 bytes |
| MAC address table size | 2K entries |
| Connector | 2-pin industrial DC power socket |
